594,020 sets of Type II Fastening Systems for the new Haoji Railway Link Project
Jun 24, 2023
The connection line between Haoji Railway and Baoxi Railway is located in Baota District, Yan'an City, Shaanxi Province. Yanjiagou Line Station is newly established at the south end of Panlong Town Station of Baoxi Railway in the north, and Yuhuangmiao Line Station is newly established at the south of Yan'an East Station of Haoji Railway in the south. .
The total length of the connecting line between Haoji Railway and Baoxi Railway is 8.933km; among them, the subgrade length of the section is 1.199km, and the earthwork is 167,200 cubic meters; there are 4 single-track super bridges of 3412.44m, 1 single-track bridge of 304.78m, and 107 holes of prefabricated and erected T beams , 4 culverts; 4 tunnels, including double-track tunnels with a length of 1111m/1 and single-track tunnels with a length of 1560.443m/3; bridges and tunnels accounted for 86.3% of the total; 8.75 km of track laying for the main line, 0.36 kilometers of track laying for the station line, and new 6 sets of turnouts;
In 2023, Anyang Railway Equipment Co., Ltd. will provide 594,020 sets of Type II Fastening Systems for the new Haoji Railway Link Project, the products are carried out TB/T 3065-2020 Standard.
The total length of the connecting line between Haoji Railway and Baoxi Railway is 8.933km; among them, the subgrade length of the section is 1.199km, and the earthwork is 167,200 cubic meters; there are 4 single-track super bridges of 3412.44m, 1 single-track bridge of 304.78m, and 107 holes of prefabricated and erected T beams , 4 culverts; 4 tunnels, including double-track tunnels with a length of 1111m/1 and single-track tunnels with a length of 1560.443m/3; bridges and tunnels accounted for 86.3% of the total; 8.75 km of track laying for the main line, 0.36 kilometers of track laying for the station line, and new 6 sets of turnouts;
In 2023, Anyang Railway Equipment Co., Ltd. will provide 594,020 sets of Type II Fastening Systems for the new Haoji Railway Link Project, the products are carried out TB/T 3065-2020 Standard.
| No. | Products | Specification | Material | Standard | Unit | Qty |
| 1 | Fastening System | Type II Fastening System(without coating) | Special Line 3351 | Sets | 29090 | |
| 1) | Screw Spike | M24*195mm | Q235- A | Pcs | 58180 | |
| 2) | Nut | Q235- A | GB/T 41 | Pcs | 58180 | |
| 3) | Flat Washer | Q235- A | Pcs | 58180 | ||
| 4) | Rail Clip | Type II | 60Si2C rA | Pcs | 58180 | |
| 5) | Guide plate | 6#, 10# | Q235- A | Pcs | 58180 | |
| 6) | Rubber Pad | 60-10-190 | Rubber | Pcs | 29090 | |
| 7) | Baffle Seat | 2-4#/0-6# | Polyamide 66 | Pcs | 58180 | |
| 2 | Fastening System | Type II Fastening System(with coating) | Special Line 3351 | Sets | 13340 | |
| 1) | Screw Spike | M24*195mm | Q235- A | Pcs | 26680 | |
| 2) | Nut | Q235- A | GB/T 41 | Pcs | 26680 | |
| 3) | Flat Washer | Q235- A | Pcs | 26680 | ||
| 4) | Rail Clip | Type II | 60Si2C rA | Pcs | 26680 | |
| 5) | Guide plate | 6#, 10# | Q235- A | Pcs | 26680 | |
| 6) | Rubber Pad | 60-10-190 | Rubber | Pcs | 13340 | |
| 7) | Baffle Seat | 2-4#/0-6# | Polyamide 66 | Pcs | 26680 | |
| Total | 594020 |
